Model

 I755ADZ37YA

Camera

Image Sensor

1/2.7" 5MP CMOS

Effective Pixels

2888H x 1628V

Electronic Shutter

AUTO, 1/25s ~ 1/100000s

Min. Illumination

0.01Lux@F1.2(AGC ON), 0Lux IR on

Day/Night

Auto/Color/(B/W)/Timing

WDR

2-Exposure Line WDR upto 100dB

White Balance

Auto/Manual

AGC/BLC/HLC

Support

DNR

2D/3D DNR

Other

Multi-lines OSD, Privacy Mask, ROI, Watermark, Low Shutter, Scenes

Encode

Video Standard

H.264/H.265

Video Resolution

Main Stream:
25fps@5MP(2880x1620)/4MP(2560x1440), 30fps@3MP(2304x1296)/1080P

Sub stream: 30fps@720P/D1/640x360/CIF

Third stream: D1, 640x360,CIF

Video Bitrates

128kbps – 6144kbps, VBR/CBR

Audio Standard

G.711-u/G.711-a

Built-in Mic

Yes

Intelligent Detection

Human Detection, Vehicle Detection

Cross Line, Enter Area, Leave Area, Intrusion, People Flow Counting, Crowd Density Monitoring

Leds and distance

Leds

2PCS dual Light LEDs

Warm light distance

25-30 M

IR Distance

25-30 M

Lens

Focal length

HD 2.8mm F1.6 lens

Functions

Two way audio, Built in Microphone and Speaker

Network Services

Protocol

HTTP(s)/IPv6/TCP/UDP/RTP/RTSP/FTP/SMTP/DDNS/DHCP/PPPoE/NTP, etc.

P2P

Yes

Web

IE, Firefox, Chrome, Edge, Safari, etc.

Media

CMS, Android, IOS

ONVIF

17.06 compatible

General

Network Port

POE ,1-RJ45, 100Mbps

Power Supply

12 VDC ± 10%

Power Consumption

< 5 W

Operating Temp.

-30℃-(+60)℃, 10%-90%RH
