4K 8MP (NVP2481H+OS08A10)

T988AHBB97A

4K 8MP UHD 4-in-1 IR Dome Camera

Features:
4-in-1 HDTVI/HDCVI /AHD / CVBS optional output
4K resolution 3840 x 2160P
Ultra low illumination 0.01Lux
Up to 300M long distance and high speed real time monitoring
OSD menu control up the coaxial cable (UTC)
Day/Night (ICR), AWB, AGC, BLC, 2D/3D-DNR
D-WDR, Defog, Privacy Mask, Mirror
Lightning protection
Strong water-proof housing, IP66
18 pcs new array IR Leds, IR distance 20-30 meters
HD 3.6 mm fixed lens

    Technical Specifications:

    Model

    YC-T988AHBB97A

    Camera

    Image Sensor

    1/1.8" 8Mega pixels Sony CMOS

    Chipset

    OS08A10+NVP2481H

    Effective Pixels

    3840(H)×2160 (V)

    Video Resolution

    8MP:HDTVI/CVI/AHD:15fps@3840x2160P, CVBS:25/30fps@960H

    Electronic Shutter

    AUTO, 1/25 - 1/50,000s

    Min. Illumination

    0.01Lux@F1.2(AGC ON), 0Lux IR on

    Video System

    PAL/NTSC

    Video Output

    1 -BNC, HDCVI / HDTVI/AHD/CVBS , adjustable

    Video Switch

    Dip Switch

    Day/Night

    Auto/Color/(B/W)/EXT

    WDR

    Digital WDR

    White Balance

    AWB/ATW/Indoor/Outdoor/Manual

    AGC/BLC

    Support

    DNR

    2D 3D NR

    OSD Menu

    Multiple languages OSD menu control up the coaxial cable (UTC)

    Other

    Defog, Privacy Mask, Mirror, Flip

    IR Led

    IR Led

    18 pcs SMD IR Leds

    IR Distance

    20-30 M

    Lens

    Focal length

    3.6 mm fixed lens

    General

    Power Supply

    12 VDC ± 10%

    Power Consumption

    < 5 W

    Operating Temp.

    -20-(+60), 10%-90%RH
