Model

W728CB97SA

Camera

Image Sensor

1/2.8" SONY IMX415 CMOS

Effective Pixels

3840 (H) × 2160 (V)

Electronic Shutter

AUTO, 1/25s ~ 1/100000s

Min. Illumination

0.01Lux@F1.2(AGC ON), 0Lux IR on

Day/Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR

White Balance

Auto/Indoor/Outdoor

BLC

Support

DNR

2D/3D DNR

Other

Motion Detection, Privacy Mask, Mirror, flip

Encode

Embedded Solution

SSC339Q

Video Standard

H.264/H.265

Video Resolution

MainStream:30/25fps@8MP(3840x2160)/6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc.

Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc.

Third stream:1080P/720P/CIF@10fps

Video Bitrates

512Kbps - 12Mbps, VBR/CBR

Audio Standard

G.711-u/G.711-a

OSD Overlay

Title and Time overlay

Audio

Optional

Micro SD slot

Yes (Max support 256G card)

Reset

Reset button

Smart Event

Motion detection

Human detection

Vehicle detection

Leds

Leds

2PCS Soft & Warm Supplemental Light

Light Distance

20-30 M

Lens

Focal length

HD 2.8/3.6mm F1.0 true starlight lens optional

Network Services

Protocol

HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.

P2P

Yes

Web

IE , Firefox, etc.

Media

CMS, Android, IOS

ONVIF

17.06 compatible

General

Network Port

1-RJ45, 100Mbps, POE

Power Supply

12 VDC ± 10%

Power Consumption

< 8 W

Operating Temp.

-30℃-(+60)℃, 10%-90%RH
