Model

W705AHBB94CA

Camera

Image Sensor

1/3" CMOS

Effective Pixels

5 megapixels

Electronic Shutter

AUTO

Min. Illumination

0.1Lux@F1.2(AGC ON), 0Lux IR on

Day/Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR

White Balance

Auto/Manual

BLC

Support

DNR

2D/3D DNR

Other

Multi-lines OSD, Motion Detection, Privacy Mask, Mirror

Encode

Video Standard

H.264/H.265

Video Resolution

Main Stream:
25fps@5MP(2592x1944),25fps@3MP/1080P/720P

Sub stream: VGA/360P@25fps, etc.

Video Bitrates

32Kbps - 8Mbps, VBR/CBR

Audio Standard

G.711-u/G.711-a

Built-in Mic

Yes

OSD Overlay

Title and Time overlay

IR Led

IR Led

18 SMD ARRAY IR Leds

IR Distance

20-30meters

Lens

Focal length

2.8MM Fixed lens

Optional Function

POE, Audio, etc.

Network Services

Protocol

HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.

P2P

Yes

Web

IE , Firefox 32bit ESR, etc.

Media

CMS, Android, IOS

ON-VIF

17.06 compatible

General

Network Port

1-RJ45, 100Mbps, POE optional

Power Supply

12 VDC ± 10%

Power Consumption

< 5 W

Operating Temp.

-30℃-(+60)℃, 10%-90%RH
