Model

W608FCZ57FA

Camera

Image Sensor

1/2.8" SONY IMX415 CMOS

Effective Pixels

3840 (H) × 2160 (V)

Electronic Shutter

AUTO, 1/25s ~ 1/100000s

Min. Illumination

0.001Lux@F1.2(AGC ON), 0Lux IR on

Day/Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR

White Balance

Auto/Indoor/Outdoor

BLC

Support

DNR

2D/3D DNR

Other

Motion Detection, Privacy Mask, Mirror, flip

Encode

Embedded Solution

Mstar 328Q

Video Standard

H.264/H.265

Video Resolution

Main Stream:20fps@8MP(3840x2160),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc.

Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc.

Video Bitrates

512Kbps - 12Mbps, VBR/CBR

Audio Standard

G.711-u/G.711-a

OSD Overlay

Title and Time overlay

Leds

Leds

4PCS Soft & Warm Supplemental Light

Light Distance

30-40 M

Lens

Focal length

HD 2.8mm F1.0 true starlight lens

Optional Functions

Audio/SD card slot (support maximum 256GB SD card )

Network Services

Protocol

HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.

P2P

Yes

Web

IE , Firefox, etc.

Media

CMS, Android, IOS

ON-VIF

17.06 compatible

General

Network Port

1-RJ45, 100Mbps, POE

Power Supply

IEEE802.3af PoE, 12 VDC ± 10%

Power Consumption

< 8 W

Operating Temp.

-30℃-(+60)℃, 10%-90%RH
