Model

YC-M716IR-3X-V3

Camera

Image Sensor

1/2.8" Sony IMX335 CMOS

Effective Pixels

2592(H)×1944 (V)

Electronic Shutter

AUTO, 1/25s ~ 1/100000s

Min. Illumination

0.01Lux@F1.2(AGC ON), 0Lux IR on

Day/Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR

White Balance

Auto

Other

AGC,2/3 DNR,Motion Detection, Privacy Mask, Mirror, Flip

Encode

Embedded Solution

Mstar SSC30KQ

Video Standard

H.265/H.264

Video Resolution

Main Stream:

25fps@5MP(2592x1944),

30fps@4MP/3MP/1080P/720P

Sub stream: D1/VGA(640x480)/360P/QVGA@25fps

Video Bitrates

512Kbps - 6Mbps, VBR/CBR

Built-in Mic

Yes

Smart Event

Human Detection

Vehicle Detection
Motion Detection

IR Led

IR Led

3 pcs SMD Array IR Leds

IR Distance

30 M

Lens

Focal length

2.8-8 mm AF Motorized lens

Zoom

3x optical zoom

PTZ

Pan/Tilt Range

Pan: 0° ~ 350°; Tilt: 5° ~ 90°

Manual Control Speed

80°/Sec

Other  Function

POE

Internal POE

Reset

Cable with reset button

Network Services

Protocol

RTSP/FTP/DHCP/DDNS/NTP/SMTP/NFS

P2P

Yes

Web

IE , firefox 32bit ESR

Media

CMS, Android, IOS

ONVIF

17.06 compatible

General

Network Port

1-RJ45, 100Mbps, POE optional

Power Supply

12 VDC ± 10%

Power Consumption

< 5 W

Operating Temp.

-30℃-(+60)℃, 10%-90%RH
