Model

M716IR-HS20X-Y

Camera

Image Sensor

1/2.8" Sony CMOS

Effective Pixels

6MP@3072*2048

Electronic Shutter

AUTO, 1/10s ~ 1/100000s

Min. Illumination

0.01Lux@F1.2(AGC ON)

Day/Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR

White Balance

Auto/Manual

BLC /HLC

Support

DNR

2D/3D DNR

Other

Image adjust , Flip

Encode

Video Standard

H.264/H.265/Mjpeg

Video Resolution

Main Stream:25fps@6MP(3072x2048)/5MP(2592x1944), 30fps@4MP/3MP/1080P/720P

Sub stream: 30fps@D1/VGA/360P/CIF, etc.

Video Bitrates

512Kbps - 8Mbps, VBR/CBR

Audio Standard

G.711-u/G.711-a/AAC

Two-way Audio

Built-in Mic and speaker

Smart Detection

Smart Human body and Vehicle Detection,support Auto tracking

IR Led

IR Led

10pcs  IR Array Leds,support remotely turn on/off  IR LEDs

IR Distance

100-120 M

Lens

Focal length

4.7-94mm

IRIS

F1.6-3.5

View angle

64 - 2.9 °

Zoom

20x optical zoom

Functions

High power PoE, built in Microphone ,with SD card slot , support up to 256GB Micro SD card

PTZ

Pan/Tilt Range

Pan: 0° ~ 360°; Tilt: -5° ~ 90°

Preset Point

256

Control Speed

Pan: 0.5° ~25° /s; Tilt: 0.5° ~25° /s

A-B  Scanning

Support

Auto Cruising

Support 8 groups patrol,  Max. 16 presets in group

Power on Action

Preset/Scan/Cruise

Power-off Recovery

Support

Cruise tracking

presets Cruise can work together with auto human tracking

Network Services

Protocol

HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS/RTMP, etc.

P2P

Yes

Web

IE, Firefox, Chrome, Edge, Safari

Media

CMS, Android, IOS

ONVIF

17.06 compatible

General

Network Port

1-RJ45, 100Mbps, PoE 48V in

Power Supply

12 VDC ± 10% 2A

Power Consumption

< 22 W

Operating Temp.

-30℃-(+60)℃, 10%-90%RH
