New Product

W716AHD03

6MP HD Elevator use POE IP camera
Features:
1/2.8" Sony CMOS sensor
FHD resolution 3072x 2048P
Low illumination 0.01Lux
Day/Night, AWB/MWB,BLC, HLC, 2D/3D-DNR,Shutter, IR-CUT
D-WDR,Mirror, rotate, Defogging
Multiply Style OSD Overlay,Motion Detection, Privacy Mask
RTSP and Onvif 17.06 compatible with many third-party NVR
H.264/H.265 dual-stream media server
Easy-to-use P2P Cloud service
Support user authentication, video data encryption
Support Alarm Snapshot to Email and FTP
Multiply WEB browser IE,Firefox 32bit ESR, PC Client, Mobile APP remote access
RJ45 100mbps network port, IEEE802.3af PoE
Lightning protection 4000V
1pcs SMD IR Led, IR distance 5-8 meters
HD 2.8/3.6 mm fixed lens optional,default in 2.8mm

    Specifications:

    Model

    W716AHD03

    Camera

    Image Sensor

    1/2.8" Sony CMOS

    Effective Pixels

    6megapixels (3072*2048)

    Electronic Shutter

    AUTO, 1/25s ~ 1/100000s

    Min. Illumination

    0.01Lux@F1.2(AGC ON), 0Lux IR on

    Day/Night

    Auto/Color/(B/W)/Timing

    WDR

    Digital WDR

    White Balance

    Auto/Manual

    BLC /HLC

    Support

    DNR

    2D/3D DNR

    Other

    Human body and Vehicle detection,AGC,Motion Detection,Privacy Mask,Flip,Rotate,RIO,OSD overlay

    Encode

    Video Standard

    H.264/H.265

    Video Resolution

    MainStream:25fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc.

    Sub stream: 720x480/VGA(640x480)/360P/QVGA@25fps,etc.

    Video Bitrates

    512Kbps - 8Mbps, VBR/CBR

    Audio Standard

    G.711-u/G.711-a/AAC

    OSD Overlay

    Title and Time overlay ,custom color adjustable

    IR Led

    IR Led

    1 pcs SMD IR Led

    IR Distance

    5-8 M

    Lens

    Focal length

    HD 2.8/3.6 mm fixed lens optional,default in 2.8mm

    Horizontal FOV

    106.9 degree

    Vertical FOV

    56.9 degree

    Diagonal FOV

    127.9 degree

    Network Services

    Protocol

    HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS, etc.

    P2P

    Yes

    Web

    IE , Firefox,Edge, Google Chrome etc.

    Media

    CMS, Android, IOS

    ONVIF

    17.06 compatible

    General

    Network Port

    1-RJ45, 100Mbps, POE

    Power Supply

    12 VDC ± 10%,POE

    Power Consumption

    < 8 W

    Operating Temp.

    -30-(+60), 10%-90%RH
