Model

YC-W744DZ58A

Camera

Image Sensor

1/2.9" GC2063 CMOS x2

Effective Pixels

4 megapixels

Electronic Shutter

AUTO, 1/25s ~ 1/100000s

Min. Illumination

0.01Lux@F1.2(AGC ON)

Day/Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR

White Balance

Auto/Manual

BLC /HLC

Support

DNR

2D/3D DNR

Other

AGC,Motion Detection,Privacy Mask,Flip ,OSD overlay

Encode

Video Standard

H.264/H.265/H.265+

Video Resolution

MainStream:20fps@3840x1080P

Sub stream: 20fps@1280x360

Video Bitrates

512Kbps - 8Mbps, VBR/CBR

Audio Standard

G.711-u/G.711-a/AAC

Built-in Mic

Yes

Built-in Speaker

Yes Two-way audio

Smart Detection

Human Detection

Led

Led

2pcs warm-light Led + 2pcs IR Led

Distance

20-30 M

Lens

Focal length

F1.6 3.6 mm fixed lens

FOV

170°

Other Function

PoE，Reset, SD-Slot

Network Services

Protocol

HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS, etc.

P2P

Yes

Web

IE , Firefox (32bit esr), etc.

Media

CMS, Android, IOS

ONVIF

17.06 compatible

General

Network Port

1-RJ45, 100Mbps, POE optional

Power Supply

12 VDC ± 10%

Power Consumption

< 10 W

Operating Temp.

-30℃-(+60)℃, 10%-90%RH
