Model

NVR3216-P16

Video/Audio Input

IP Video Input

16-ch

Two-way Audio Input

1-ch, RCA

Network

Incoming Bandwidth

112Mbps

Outgoing Bandwidth

96Mbps

Remote Users

128

Protocols

,P2P, UPnP, NTP, DHCP, PPPoE

Video/Audio Output

HDMI/VGA Output

VGA:

1024X768@60,1280X720@60,1280X1024@60,1920X1080@50,1920X1080@60

HDMI:

4k(3840x2160@30),4k(3840x2160@60),1024X768@60,1280X720@60,1280X1024@60, 1920X1080@50, 1920X1080@60

Recording Resolution

8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF

Audio Output

1-ch, RCA

Synchronous Playback

16-ch

Corridor Mode Screen

3/4/5/7/9/10/12/16

Decoding

Decoding format

Ultra 265, H.265, H.264

Live view/Playback

8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/960H/D1/2CIF/CIF

Capability

1 x 4K@30, 2 x 4MP@30, 3 x 3MP@25, 4 x 1080P@30, 8 x 720P@30,16 x D1

Hard Disk

SATA

2 SATA interfaces

Capacity

Up to 10TB for each HDD

eSATA

NO

External Interface

Network Interface

1 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces

USB Interface

Front panel: 1 x USB2.0, Rear panel: 1 x USB2.0

Alarm In

4-ch

Alarm Out

1-ch

POE

Interface

16 independent 100Mbps PoE network interfaces

Max Power

Max 30W for single port

Max 240W in total ( 15W for each )

Supported Standard

IEEE 802.3af/at

General

Power Supply

100~240 VAC

Power Consumption: ≤ 9 W(without HDD)

Working Environment

-10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing)

Dimensions (W×D×H)

380mm ×315mm × 49.1mm(15.0" × 12.4" ×1.9" )

Weight (without HDD)

≤2.4kg (5.29 lb)
