Model

YC-W945AHZ37HA

Camera

Image Sensor

1/2.8" Sony IMX335 STARVIS CMOS

Effective Pixels

5 megapixels

Electronic Shutter

AUTO

Min. Illumination

0.01Lux@F1.2(AGC ON)

Day/Night

Auto/Color/(B/W)

System

PAL/NTSC

White Balance

Auto/Indoor/Outdoor

OSD Overlay

Yes

Image Mirror

Yes

Privacy Mask

Yes

Encode

Video Standard

H.265/H.264

Video Resolution

Main Stream:15fps@5MP/4MP

Sub Stream: 30fps@800x600/640x352

Video Bitrates

32Kbps - 6Mbps, VBR/CBR

Audio Standard

G.711/G.726

Audio Input

Built-in Mic

Audio Output

Built-in loudspeaker

Two-way Audio

Yes

IR Led

IR Led

12 pcs SMD IR Leds

IR Distance

10-20 M

Lens

Focal length

2.8/3.6mm Fixed lens

Network Services

Protocol

TCP/IP/HTTP/RTSP/FTP/SMTP/DHCP/NTP, etc.

P2P

Yes

Web

IE , Firefox, Chrome, Edge, Safari, etc. (flash video)

Media

CMS, Android, IOS

ONVIF

2.04 compatible

Alarm Event

Sound Alarm, Motion Detection, Email alert, snapshot FTP, SD Storage

General

Network Port

1-RJ45, 100Mbps

Wireless

2.4G b/g/n external 3DB antenna

Reset Button

Yes

Power Supply

12 VDC ± 10%

Power Consumption

< 10 W

Operating Temp.

-30℃-(+60)℃, 10%-90%RH
